Model NO.:
GB 15831, EN 39, EN 10219, BS 1139, BS 1387-1985, JIS G 3444
Keywords: Scaffolding Tube, GI Pipe, Scaffolding Pipe, Galvanized Scaffolding Pipe
Size: (2)OD:38.1mm/42.3mm/48.3mm/48.6mm;WT:2.0mm/2.5mm/2.75mm/3.0mm/3.25mm/3.85mm/4.0mm;LENGTH: 0.3mtr ~ 18mtr
Standard & Grade: GB 15831, EN 39, EN 10219, BS 1139, BS 1387-1985, JIS G 3444
Ends: Square Cut, Plain End, Burr Removed
Delivery: Within 30 days and Depends on your order quantity.
Payment: TT, LC , OA , D/P
Packing: Bundles with strips, Waterproof Paper Wrapped or as clients requirement
Usage: Used for low pressure liquid delivery, such as water, gas, and oil
Quantity:

Use: Scaffolding is a temporary structure used to support people and material in the construction or repair of buildings and other large structures. Material Storage Racks, Pallets, Hydraulic Platforms, Trusses, Columns, Purlins, Greenhouse, Stands Towers, Agricultural Equipment

Standard: BS 1139, BS1387-1985, EN 39, EN10219, JIS G 3444

Certificate: EN10217, EN10219, API 5L PSL1/ PSL2, API 5CT

Out Diameter: 27mm, 38mm, 42mm, 48.3mm-48.6mm

Wall Thickness: 2.0mm, 2.5mm, 2.75mm, 3.0mm, 3.25mm, 3.85mm, 4.0mm

Length: 5.8m, 6m, 6.4m, 6.5m, 0.3-18m

End: Square cut, Burr removed

Steel Grade: Q195, Q215, Q235, Q345, S235JR, S275JR, STK400, STK500

Surface: Lightly oiled, Hot dip galvanized, Electro galvanized, Black

Packing: Plastic plugs in both ends, Wrapped in waterproof paper or PVC sleeve, and sackcloth with several steel strips Plastic plugs in both ends.

Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Flaring Test, Bending Test, Hardness Test, Blow Test, Impact Test etc), Exterior Size Inspection.

Mill Test Certificate: EN 10204/3.1B

Payment Terms: T/T, L/C

Production Time 7-40 days
Delivery Time 7-40 days
Trade terms: FOB, CFR, CIF
Delivery Detail:Depends on your order quantity.
Packaging Detail: Packing in bundles or for the client’s requirement
Supply Ability: 500 Metric Ton/Metric Tons per Day
