Model NO.:
ASTM A106, Grade A/B/C etc
Pipe Type: Seamless Pipe, Seamless Carbon Steel Pipe, Carbon Steel Seamless Pipe
Application: For High Temperature Service, High Temperature Fluids Transmission (oil, gas, water, steam etc.)

Specification: OD: 1/8'' ~ 48'' (10.3 ~ 1219mm)
WT: SCH 10 ~ 160, SCH STD, SCH XS, SCH XXS

LENGTH: Fixed Length (5.8/6/11.8/12mtr), SRL, DRL

Standard & Grade: ASTM A106, Grade A/B/C

Ends: Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends

Surface: Bare, Lightly Oiled, Black/Red/Yellow Painting, Zinc/Anti-corrosive Coating

Packing: Bundled/In Bulk, Plastic Caps Plugged, Waterproof Paper Wrapped
Quantity:

Seamless Steel Pipe Manufacturing Process

Mandrel Mill Process

In the Mandrel Mill Process, a solid round (billet) is used. It is heated in a rotary hearth heating furnace and then pierced by a piercer. The pierced billet or hollow shell is rolled by a mandrel mill to reduce the outside diameter and wall thickness which forms a multiple length mother tube. The mother tube is reheated and further reduced to specified dimensions by the stretch reducer. The tube is then cooled, cut, straightened and subjected to finishing and inspection processes before shipment.

Manner man plug mill process

In the Plug Mill Process, a solid round (billet) is used. It is uniformly heated in the rotary hearth heating furnace and then pierced by a Manner man pieces. The pierced billet or hollow shell is roll reduced in outside diameter and wall thickness. The rolled tube simultaneously burnished inside and outside by a reeling machine. The reeled tube is then sized by a sizing mill to the specified dimensions. From this step the tube goes through the straightener. This process completes the hot working of the tube. The tube (referred to as a mother tube) after finishing and inspection, becomes a finished product.
